51.2V 100Ah Wall Mounted Battery Storage A Grade EVE Cells

SWP 51.2V 100Ah Residential Powerwall home Energy Storage system LiFePO4 Battery A Grade EVE 100Ah cells

Product Description:

Energy Storage Capacity: Wall-mounted battery storage systems come in various capacity options, typically measured in kilowatt-hours (kWh). The capacity determines how much energy the system can store and supply to your home.

Integration with Solar Power: Many wall-mounted battery storage systems are designed to work seamlessly with solar panels. They can store excess solar energy generated during the day for later use, maximizing self-consumption and reducing reliance on the grid.

Smart Energy Management: Some wall-mounted battery storage systems incorporate advanced energy management features. These systems can intelligently optimize energy usage, such as charging the battery during off-peak hours when electricity rates are lower and discharging it during peak hours to reduce costs.

Monitoring and Control: Many systems provide monitoring and control capabilities through dedicated mobile apps or online platforms. These allow you to track energy usage, battery status, and even remotely control the system settings for optimal performance.

Scalability: Wall-mounted battery storage systems often offer the option to expand the capacity by adding additional units. This scalability allows you to increase your energy storage capabilities as your needs grow or as technology advances.

Safety Features: Battery storage systems prioritize safety with features such as thermal management systems, overcurrent protection, and built-in circuit breakers to prevent damage or accidents.

Environmental Benefits: By using a wall-mounted battery storage system, you can reduce your carbon footprint by maximizing the utilization of renewable energy sources and minimizing reliance on fossil fuel-based power generation.

SWP51100-PW Power Wall Energy Storage System
Electrical specifications	Nominal Voltage	51.2V
	Nominal Capacity	100Ah
	Parallel Connection	Max. 16 units
	BMS	16S100A
	Circuit Protection	Over charge, Over discharge, Over current, Over temp, Short, Balance
	Communication	RS232 RS485 and CAN
	Cycle Life	3000 times cycles @ 100% DOD and 6000 times @ 80% DOD
	Self Discharge	Less than 3% per month
	Charge Efficiency	100% @ 0.2C
	Discharge Efficiency	98%-100% @ 1C
Charge Specifications	Charge Voltage	57.6V±0.8V
	Standard Current	50A
	Fast Current	100A
Discharge Specifications	Standard Current	100A
	Max.Con.Discharge	200A
	Cut-Of Voltage	40±0.2V
Mechanical Specifications	Dimension (mm)	Customized
	Approx Weight (KG)	50
	Terminal Type	KT8-10-2P Fence terminal 0r Plug-in terminal
	Cases Color/Material	Black / Siliver / White Metal Cases
	Cells Type	EVE 3.2V100Ah
Temperature Specifications	Charge Temp	0℃-55℃ (32℉-131℉)
	Discharge Temp	-20℃-60℃ (-4℉-140℉)
	Storage Temp	-20℃-45℃ (-4℉-113℉)
Battery Type		LiFePO4
Cycle		The cycle life shall not be less than 3000 times when DOD is 100%. The cycle life shall not be less than 6000 times at 80% DOD.(Charge according to standard charge, put it aside After 0.5～1h; discharge according to the standard, put it aside for 0.5～1h, count as 1 cycle).
Certificate		UL1642(Cell), IEC62133(Cell), IEC62619 (Cell), CE(Pack), UN38.3 (Cell / Pack) , ROHS (Cell)
After-sales service period		5 Years
Estimate useful life		≥10 Years
With Display		Yes

Features:

• Product Name: Wall Mounted Battery Storage
• Mounting Method: Wall Mounted
• Storage Temperature: -20℃~+50℃
• Warranty: 5 Years
• Voltage: Customizable
• Material: Aluminum Alloy
• Home Energy Storage System: Salor Energy Battery
• Battery Type: LiFePO4 Battery

Technical Parameters:

Product Attributes	Specifications
Size	Customizable
Working Temperature	-20℃~+50℃
Protection Level	IP65
Life Cycle	Over 6000 Times
Capacity	Customizable
Application	Outdoor
Material	Aluminum Alloy
Voltage	Customizable
Warranty	5 Years
Storage Temperature	-20℃~+50℃

Applications:

This wall mounted battery storage system from SWP is the perfect solution for energy storage in any home or office. It is designed with an easy installation process and made of durable aluminum alloy, so it can withstand the test of time. It has a storage temperature range of -20℃ to +50℃ and a working temperature range of -20℃ to +50℃. It is also backed by a 5-year warranty, giving you peace of mind that you are investing in a reliable product.

The SWP Wall Mounted Battery Storage System is the perfect way to power up your home or office. It stores energy from your home's power wall system which is available at any time. This makes it easy to access your energy whenever you need it, and is great for backup power when the power goes out. With its easy installation, you can save time and money by not having to hire a professional to install it.

The SWP Wall Mounted Battery Storage System is the perfect way to save money and energy. By using the stored energy from your home's power wall system, you are able to save money on your power bills. It also helps you to be more energy efficient, as you are able to use the stored energy whenever you need it. This makes it an ideal solution for anyone looking for a reliable and efficient way to store energy.

The SWP Wall Mounted Battery Storage System is the perfect way to store energy and power up your home or office. With its easy installation, durable aluminum alloy construction, and 5-year warranty, you can have peace of mind that you are investing in a reliable product. It has a storage temperature range of -20℃ to +50℃ and a working temperature range of -20℃ to +50℃, making it an ideal solution for any home or office.

Customization:

• Brand Name: SWP
• Model Number: SWP-48100RM
• Place of Origin: China
• Working Temperature: -20℃~+50℃
• Size: Customizable
• Warranty: 5 Years
• Material: Aluminum Alloy
• Product Name: Wall Mounted Battery Storage
• Salor Energy Battery, Energy Storage Battery, Energy Storage Battery System

Support and Services:

Wall Mounted Battery Storage offers technical support and services to ensure your product is working correctly and efficiently.

We provide technical support via phone, email, and live chat, so you can get help quickly and easily. We also offer a wide range of services such as installation, maintenance, and repairs.

Our experienced and knowledgeable technicians are available to answer any questions you may have about your product, as well as provide guidance on how to best utilize it to suit your needs.

We strive to provide the best customer service experience possible, and we are committed to making sure you are completely satisfied with our products and services.

Packing and Shipping:

Wall Mounted Battery Storage is packaged in an individual box and shipped with a protective padding material. The box is designed to protect the product from any potential damage during shipping.

The box is robust and suitable for shipping in any weather conditions. It is also designed to protect the product from any potential water damage.

The product is shipped in a secure box and is secured with bubble wrap, foam or other protective material. The product is also shipped with appropriate labels for easy identification.

FAQ:
