5000W Inverter Stackable Battery Storage 5~15Kwh Safety Protection

Product Details

Place of Origin: China

Brand Name: stackable battery system

Certification: UL, MSDS, UN38.3, CE

Model Number: SWP-51S

Payment & Shipping Terms

Minimum Order Quantity: 100

Packaging Details: Carton Or Wooden

Delivery Time: 25

Payment Terms: T/T, L/C

Supply Ability: 100PCS/Day

Get Best Price
Contact Now
Specifications
Highlight:

5000W Inverter Stackable Battery Storage

,

Stackable Battery Storage 15Kwh

Charge/Discharge Efficiency:
≥97%
Discharging Temperature:
-20℃~60℃
Safety Protection:
DC Revese Polarity /AC Short Circuit /Leakage/battery Input Reverse Polarity
Warranty:
5 Years
Voltage:
40V~58.4V
Weight:
135Kg/Module
Charging Temperature:
0℃~45℃
Product Name:
Stackable Battery Storage
Charge/Discharge Efficiency:
≥97%
Discharging Temperature:
-20℃~60℃
Safety Protection:
DC Revese Polarity /AC Short Circuit /Leakage/battery Input Reverse Polarity
Warranty:
5 Years
Voltage:
40V~58.4V
Weight:
135Kg/Module
Charging Temperature:
0℃~45℃
Product Name:
Stackable Battery Storage
Description
5000W Inverter Stackable Battery Storage 5~15Kwh Safety Protection

5~15Kwh Safety Protection Stackable Battery Storage 5000W Inverter DC Revese Polarity/AC Short Circuit/Leakage

Product Description:

Introducing Stackable Battery Storage, a state-of-the-art Battery Energy Storage System designed for Domestic Battery Energy Storage and Household Energy Storage Battery. Stackable Battery Storage is designed with versatility in mind, offering a compact, space-saving form factor with a wide range of operating temperatures, from -20℃ to 60℃. It is also surprisingly lightweight, weighing only 52Kg per module, making it easy to install and transport. Most importantly, Stackable Battery Storage offers an impressive cycle life of up to 6000 cycles, and an industry-leading charge/discharge efficiency of ≥97%. With Stackable Battery Storage, you can enjoy reliable, long-lasting energy storage for your home.

MODEL TH-51-SP
Nominal Dc voltage 51 .2V
Battery capacity 100Ah 200Ah(100Ah*2)
Energy(kwh) 5kwh 10kwh
Maximum Discharging current 100A
cycle Life 6000cycles(80%DOD)
certification UN38.3,MSDS,CE-EMC,IEC62619,UL1973



System GeneralData

Temperature range -20~60℃
Environmenthumidity 0-95%
Dimensions (H*w*D)mm 1510*670*176mm 1895*670*176mm
Netweight (kg 135KG 270KG
communicationmethod WIFl/4G
Grid connection certification CE-LVD;CE-EMC;EN50549;1/CEI-021;VDE4105/0124;G99;IEC61727/62116/61683;NA/EEA-NE7-CH2020

5000W Inverter Stackable Battery Storage 5~15Kwh Safety Protection 05000W Inverter Stackable Battery Storage 5~15Kwh Safety Protection 1

Model SWP-3600ST SWP-5000ST SWP-6000ST

PV input (DC)

Recommend Max.PV input power 8700Wp 10000Wp 11000Wp
Max.PVVoltage 600V
Min.operation/start-up voltage 40V / 50V
Rated PV input voltage 360V
No.ofindependentMPPTinputs/strings 2/1



Protection & Function

Protection DC Revese Polarity /AC Short circuit /Leakage/battery input reverse polarity
Surge Protection DC type Ⅱ/AC type Ⅱ
DC swith (PV)/DC fuse(battery) Yes
Battery input reverse polarity protection Yes



General Data

Dimensition(W*H*D) 1510*365*180mm
Weight ≤20Kg
Degree Of Protection IP65
Operating ambient emperature rang -25℃~60℃,0~100%
Max.Operating Altitude 4000m



General Data

Rated Output Power For Backup Load 6000W



Backup Data(Off-Grid Model)

Rated Voltage 220V/230V/240V(±2%)
Frequency Range 50HZ/60HZ(±0.5%)
Rated out power 3680W/3680VA 5000W/5000VA 5000W/6000VA
Peak ourput power 8400VA.10S

Features:

  • Product Name: Stackable Battery Storage
  • Cycle Life: ≥6000
  • Charge/Discharge Efficiency: ≥97%
  • Charge/Discharge Current: ≤100A
  • Discharging Temperature: -20℃~60℃
  • Battery Storage Container: Stackable design for easy storage
  • Battery Energy Storage System: Integrated Battery Energy Storage System for home solar storage
  • Home Solar Battery Storage: Enable Home Solar Battery Storage with a simple plug and play installation
5000W Inverter Stackable Battery Storage 5~15Kwh Safety Protection 2

Technical Parameters:

Product Name Stackable Battery Storage
Voltage 40V~58.4V
Charging Temperature 0℃~45℃
Discharging Temperature -20℃~60℃
Operating Temperature -20℃~60℃
Weight 52Kg/Module
Warranty 5 Years
Cycle Life ≥6000
Safety Protection DC Revese Polarity / AC Short Circuit / Leakage / Battery Input Reverse Polarity
Charge/Discharge Efficiency ≥97%
Keywords Energy Storage Battery Pack, Home Solar Battery Storage System, Battery Energy Storage System


Applications:

The Stackable Battery System (Model Number SWP-51S) is a reliable energy storage battery pack ideal for industrial battery storage systems, domestic battery energy storage, and remote power sources. It has been certified to UL, MSDS, UN38.3, and CE safety standards, and requires a minimum order quantity of 100 units. With a fast delivery time of 25 days, its charge/discharge current is limited to ≤100A. It boasts a cycle life of ≥6000, and is designed to operate over a wide temperature range of -20℃~60℃. The voltage range is 40V~58.4V, and the safety protection includes DC Reverse Polarity, AC Short Circuit, Leakage, and Battery Input Reverse Polarity.

5000W Inverter Stackable Battery Storage 5~15Kwh Safety Protection 3

Customization:

Stackable Battery Storage - SWP-51S

Brand Name: Stackable Battery System

Model Number: SWP-51S

Place of Origin: China

Certification: UL, MSDS, UN38.3, CE

Minimum Order Quantity: 100

Delivery Time: 25

Operating Temperature: -20℃~60℃

Voltage: 40V~58.4V

Charging Temperature: 0℃~45℃

Charge/Discharge Efficiency: ≥97%

Cycle Life: ≥6000

Features:
  • Ideal for Home Energy Storage Battery applications.
  • Highly efficient Commercial Battery Storage System.
  • High quality components for Home Solar Battery Storage.


Support and Services:

Stackable Battery Storage Technical Support and Service

At Stackable Battery Storage, we strive to provide the best technical support and service to our customers. We are committed to providing you with comprehensive customer service and technical support to ensure your satisfaction with our products. Our technical support team is available to answer any questions or concerns you may have about our products.

Our team of experts is available to provide technical advice, troubleshooting assistance, and guidance for installation and maintenance of our product. In addition, we provide comprehensive product documentation and tutorials to help you get the most out of your Stackable Battery Storage product.

If you ever need help with your product, don't hesitate to contact our technical support team. We are available to assist you 24 hours a day, 7 days a week. Our team of experienced professionals is here to make sure that your experience with Stackable Battery Storage is an enjoyable one.

5000W Inverter Stackable Battery Storage 5~15Kwh Safety Protection 4

Packing and Shipping:

Packaging and Shipping

Stackable Battery Storage products must be packaged properly to ensure a safe and secure shipment. The following guidelines should be followed to ensure all products are properly handled and shipped:

  • Use a double-walled cardboard box, with a minimum of 2 inches of foam padding, to protect the product during shipment.
  • Ensure that all boxes containing Stackable Battery Storage products are clearly labeled as “FRAGILE”.
  • Do not stack more than two boxes containing Stackable Battery Storage products.
  • Do not ship Stackable Battery Storage products with other items in the same box.
  • For international shipments, provide all necessary documentation to ensure a successful delivery.
5000W Inverter Stackable Battery Storage 5~15Kwh Safety Protection 5

FAQ:

Q1: What is the brand name of this product?
A1: The brand name of this product is Stackable Battery System.
Q2: What is the model number of this product?
A2: The model number of this product is SWP-51S.
Q3: What is the place of origin of this product?
A3: The place of origin of this product is China.
Q4: What certifications does this product have?
A4: This product has UL, MSDS, UN38.3, and CE certifications.
Q5: What is the minimum order quantity for this product?
A5: The minimum order quantity for this product is 100.
Q6: How long does it take for delivery?
A6: Delivery usually takes 25 days.
