Product Details
Place of Origin: China
Brand Name: SWP
Certification: UL, MSDS, UN38.3, CE，IEC
Model Number: SWP-48100FS
Payment & Shipping Terms
Minimum Order Quantity: 200
Packaging Details: Carton Or Wooden
Delivery Time: 25
Payment Terms: T/T, L/C
Supply Ability: 500PCS/Day
Voltage: |
3.7V-4.2V |
Weight: |
80~100kg |
Cost: |
Low |
Cycle Life: |
6000-8000 Times |
Capacity: |
100-200Ah |
Operating Temperature: |
-20℃~60℃ |
Discharge Time: |
2-4 Hours |
Charge Time: |
2-4 Hours |
Voltage: |
3.7V-4.2V |
Weight: |
80~100kg |
Cost: |
Low |
Cycle Life: |
6000-8000 Times |
Capacity: |
100-200Ah |
Operating Temperature: |
-20℃~60℃ |
Discharge Time: |
2-4 Hours |
Charge Time: |
2-4 Hours |
Lithium Battery Energy Storage Systems (BESS) are indeed a type of energy storage solution that utilizes lithium-ion batteries. These systems have gained popularity due to their high energy density, long cycle life, and excellent performance characteristics.
The capacity of a lithium battery energy storage system can vary, but in the case you mentioned, it ranges from 100-200Ah. This capacity indicates the amount of charge the battery can store, and higher Ah ratings typically correspond to greater energy storage capabilities.
One of the advantages of lithium batteries is their ability to operate reliably and safely over a wide temperature range. The battery you described is designed to work within temperatures ranging from -20℃ to 45℃. This wide temperature tolerance allows the battery to function effectively in various environments.
Safety is a critical aspect of energy storage systems, and lithium batteries have several features that contribute to their high safety performance. These batteries are equipped with advanced battery management systems (BMS) that monitor and control various parameters, including voltage, current, and temperature. The BMS ensures the battery operates within safe limits and protects against overcharging, over-discharging, and overheating.
Another advantage of lithium batteries is their long cycle life. The cycle life refers to the number of charge-discharge cycles a battery can undergo before its capacity significantly degrades. The battery you mentioned has a cycle life of up to 6000-8000 times, which means it can be charged and discharged thousands of times before its performance starts to diminish.
Lithium battery energy storage systems find applications in various fields, such as residential, commercial, and industrial sectors. They can be used for solar energy storage, load shifting, peak shaving, backup power, and grid stabilization, among others. The customizable size of these batteries allows them to be tailored to specific installation requirements.
In summary, lithium battery energy storage systems offer reliable, safe, and customizable solutions for energy storage needs. With their high energy density, wide temperature range, long cycle life, and suitability for various applications, they are indeed a great choice for energy storage solutions.
| Home Energy Storage System | SWP12-4800YA1 | SWP12-4800YAA | ||||||||
| Battery Input | ||||||||||
| Type | LFP | |||||||||
| Rated Voltage | 48V | |||||||||
| Input Voltage Range | 37-60V | |||||||||
| Rated Capacity | 4800Wh | 4800Wh | ||||||||
| Rated Charging Current | 25A | 25A | ||||||||
| Rated Discharging Current | 45A | 45A | ||||||||
| Maximum discharge current | 80A | 80A | ||||||||
| Battery Cycle Life | 2000 times (@25°C, 1C discharge) | |||||||||
| AC Input | ||||||||||
| Charging Power | 1200W | 1800W | ||||||||
| Rated Voltage | 110Vac | 220Vac | ||||||||
| Input Voltage Range | 90- 140V | 180-260V | ||||||||
| Frequency | 60Hz | 50Hz | ||||||||
| Frequency Range | 55-65Hz | 45-55Hz | ||||||||
| Power Factor (@max. charging power) | >0 .99 | >0 .99 | ||||||||
| DC Input | ||||||||||
| Maximum Input Power from Vehicle Charging |
120W | |||||||||
| Maximum Input Power from Solar Charging | 500W | |||||||||
| DC Input Voltage Range | 10~53V | |||||||||
| DC/Solar Maximum Input Current | 10A | |||||||||
| AC Output | ||||||||||
| Rated AC Output Power | 2000W | |||||||||
| Peak Power | 5000W | |||||||||
| Rated Voltage | 110Vac | 220Vac | ||||||||
| Rated Frequency | 60Hz | 50Hz | ||||||||
| Maximum AC Current | 28A | 14A | ||||||||
| Rated Output Current | 18A | 9A | ||||||||
| Harmonic Ratio | < 1 .5% | |||||||||
| DC Output | ||||||||||
| USB-A (x1) | 12 .5w, 5V, 2 .5A | |||||||||
| QC 3 .0 (x2) | Each 28w , (5V, 9V, 12V), 2 .4A | |||||||||
| USB-TypeC (x2) | Each 100w , (5V, 9V, 12V, 20V), 5A | |||||||||
| Cigarette Lighter and DC Port Maximum Output Power |
120W | |||||||||
| Cigarette Lighter(x1) | 120w, 12V, 10A | |||||||||
| DC Port (x2) | 120w, 12V, 10A | |||||||||
| Other Function | ||||||||||
| LED Light | 3W | |||||||||
| Dimensions of LCD Display (mm) | 97*48 | |||||||||
| Wireless Charging | 10W(Optional) | |||||||||
| Efficiency | ||||||||||
| Maximum Battery to AC | 92.0% | 93.0% | ||||||||
| Maxmum AC to Battery | 93% | |||||||||
| Protection | AC Output Overcurrent, AC Output Short Circuit, AC Charge Overcurrent AC Output Over/Under Voltage, AC Output Over/Under Frequency, Inverter Over Temperature AC Charge Over/Under Voltage, Battery Temperature High/Low, Battery/Under Voltage |
|||||||||
| General Parameter | ||||||||||
| Dimensions (L*W*Hmm) | 570*220*618 | |||||||||
| Weight | 54.5kg | |||||||||
| Operating Temperature | 0~45°C (Charging) ,-20~60°C (Discharging) | |||||||||
| Communication Interface | WIFI | |||||||||
| Product Property | Technical Parameters |
|---|---|
| Cycle Life | 6000-8000 Times |
| Reliability | High |
| Discharge Time | 2-4 Hours |
| Cost | Low |
| Voltage | 37V-65V |
| Weight | 80~100kg |
| Capacity | 100-200Ah |
| Size | Customized |
| Charge Time | 2-4 Hours |
| Operating Temperature | -20℃~60℃ |
| Application | Home Lithium Storage Battery, Home Solar Battery Storage System, Home Energy Storage System. |
The SWP-48200FS Lithium Battery Energy Storage System is an all-in-one home solar battery storage system that features high safety and reliable performance. It is designed with an innovative lithium battery energy storage technology, providing a stable, efficient, and green energy storage solution.
The battery system is equipped with advanced lithium battery cells and features a storage temperature of -20℃~45℃, a discharge time of 2-4 hours, and a weight of 80~100kg. The system offers superior safety, allowing the user to use it confidently and securely.
The SWP-48200FS is the ideal home solar battery storage system for those looking for a reliable, efficient, and safe energy storage solution. It is designed to meet the user’s needs and provide an all-in-one energy storage system that is both reliable and cost-effective.
SWP provides an all-in-one energy storage lithium battery system that can be customized to your needs. Our SWP-48200FS model is from China, with an affordable cost and a long lifespan of 5-10 years. It has a wide temperature range of -20℃~45℃ for storage and offers high safety.
We provide comprehensive technical support and service for our Lithium Battery Energy Storage System. Our technical support team is available 24/7 to answer your questions and provide troubleshooting assistance.
Our team of certified technicians can provide on-site service and maintenance for your system. We also have a wide range of technical documents, including user manuals, installation guides, and system diagrams, available for download.
We also offer a wide range of spare parts and replacement components for our Lithium Battery Energy Storage System. These parts are available for purchase directly from our website.
For more information about our technical support and service for Lithium Battery Energy Storage System, please contact us today.
Packaging and Shipping for Lithium Battery Energy Storage System:
Lithium Battery Energy Storage System products should be packaged in a corrugated cardboard box with at least 2 inches of cushioning material on all sides. The box should then be sealed with packing tape. The box should be clearly labeled with the product and delivery address. All shipments should be handled with care and shipped via a reputable shipping service.
Q1. What is the brand name of the Lithium Battery Energy Storage System?
A1. The brand name is SWP.
Q2. What is the model number?
A2. The model number is SWP-48100FS.
Q3. Where is the Lithium Battery Energy Storage System made?
A3. The Lithium Battery Energy Storage System is made in China.
Q4. Does the Lithium Battery Energy Storage System come with an installation guide?
A4. Yes, the Lithium Battery Energy Storage System comes with an installation guide.
Q5. Does the Lithium Battery Energy Storage System come with a warranty?
A5. Yes, the Lithium Battery Energy Storage System comes with a warranty.
