Product Description:
The Home Battery Energy Storage System is a commercial energy system designed to store excess energy from the grid and provide reliable and efficient power to homes. It offers a robust HV battery pack with a high-efficiency battery management system and a variety of safety protections. Its wall-mounted or floor-mounted installation method is ideal for home energy storage, and the system is compatible with various types of inverters. With RS232, RS485 and CAN communication interfaces, the Home Battery Energy Storage System provides a secure and reliable way to store energy and ensure a smooth power supply. It is an excellent choice for homes looking to reduce electricity costs while increasing their energy independence.
| SWP48200-RM |
| Electrical specifications |
Nominal Voltage |
51.2V |
| Nominal Capacity |
200Ah |
| Parallel Connection |
Max. 16 units |
| BMS |
16S200A |
| Circuit Protection |
Over charge, Over discharge, Over current, Over temp, Short, Balance |
| Communication |
RS232 RS485 and CAN |
| Cycle Life |
3000 times cycles @ 100% DOD and 6000 times @ 80% DOD |
| Self Discharge |
Less than 3% per month |
| Charge Efficiency |
100% @ 0.2C |
| Discharge Efficiency |
98%-100% @ 1C |
| Charge Specifications |
Charge Voltage |
57.6V±0.8V |
| Standard Current |
100A |
| Fast Current |
200A |
| Discharge Specifications |
Standard Current |
100A |
| Max.Con.Discharge |
200A |
| Cut-Of Voltage |
40±0.2V |
| Mechanical Specifications |
Dimension (mm) |
Customized |
| Approx Weight (KG) |
85 |
| Terminal Type |
KT8-10-2P Fence terminal 0r Plug-in terminal |
| Cases Color/Material |
Black Metal Cases |
| Cells Type |
EVE 3.2V100Ah |
| Temperature Specifications |
Charge Temp |
0℃-55℃ (32℉-131℉) |
| Discharge Temp |
-20℃-60℃ (-4℉-140℉) |
| Storage Temp |
-20℃-45℃ (-4℉-113℉) |
| Battery Type |
LiFePO4 |
| Cycle |
The cycle life shall not be less than 3000 times when DOD is 100%.
The cycle life shall not be less than 6000 times at 80% DOD.(Charge according to standard charge, put it aside After 0.5～1h; discharge according to the standard, put it aside for 0.5～1h, count as 1 cycle). |
| Certificate |
UL1642(Cell), IEC62133(Cell), IEC62619 (Cell), CE(Pack), UN38.3 (Cell / Pack) , ROHS (Cell) |
| After-sales service period |
5 Years |
| Estimate useful life |
≥10 Years |
Features:
- Product Name: Home Battery Energy Storage System
- Installation Method: Wall-mounted, Floor-mounted
- Capacity: 10kWh
- Operating Temperature: -20℃~50℃
- Battery Management System: Yes
- Warranty: 5years
Technical Parameters:
| Attribute |
Parameter |
| Compatible Inverter |
Yes |
| Cycle Life |
5000-8000 |
| Capacity |
5-20kWh |
| Voltage |
51.2V |
| Communication Interface |
RS232,RS485, CAN |
| Safety Protection |
Overcharge, Overdischarge, Overcurrent, Short Circuit, Temperature Protection |
| Operating Temperature |
-20℃~50℃ |
| Power |
10kW |
| Warranty |
5years |
| Battery Management System |
Yes |
Applications:
The SWP-48200RM Home Battery Energy Storage System, manufactured by SWP, is designed with 5-20kWh capacity and 3-10kW power, perfect for residential and commercial applications. It provides excellent safety protection, such as overcharge, overdischarge, overcurrent, short circuit, and temperature protection. With an operating temperature range of -20℃~50℃, this home battery energy storage system is suitable for various harsh environment, and it offers a 5-year warranty for your peace of mind. It's a reliable, efficient and cost-effective solution for salor battery storage system, energy storage battery, storage system battery.
Customization:
Home Battery Energy Storage System
SWP home battery energy storage system provides reliable power and energy storage for any home. Brand Name: SWP; Model Number: SWP-48200RM; Place of Origin: China; Communication Interface: RS232,RS485, CAN; Cycle Life: 5000-8000; Warranty: 5years; Operating Temperature: -20℃~50℃; Safety Protection: Overcharge, Overdischarge, Overcurrent, Short Circuit, Temperature Protection. This storage system battery, power wall battery, and energy storage battery are perfect for any home.
Support and Services:
Technical Support and Service for Home Battery Energy Storage System
We provide technical support and service for Home Battery Energy Storage System. Our team of experienced technicians can provide you with professional assistance.
We offer advice on system design, installation, and maintenance. We can provide detailed instructions and guidance on how to properly use and care for your Home Battery Energy Storage System. We also offer troubleshooting services to determine any underlying problems that may be causing system performance issues.
Our technicians are available to answer questions and provide assistance via telephone, email, or live chat. We strive to provide our customers with prompt and courteous service.
For more information, please contact us at arvin@swpbattery.com.
Packing and Shipping:
Packaging and Shipping for Home Battery Energy Storage System
To ensure that the Home Battery Energy Storage System is delivered safely, following packaging and shipping processes must be implemented:
- The product must be placed in a corrugated cardboard box.
- The box should be sized to fit the product and provide enough space for any other accessories or components.
- The box must be filled with packing materials to protect it during shipping.
- The box must be sealed with adhesive tape.
- The address of the recipient must be clearly marked on the box.
- The package must be shipped using a reliable courier service.
- The package must be tracked to ensure safe delivery.
FAQ:
- Q: What is the brand name of this Home Battery Energy Storage System?
- A: The brand name of this Home Battery Energy Storage System is SWP.
- Q: What is the model number of this Home Battery Energy Storage System?
- A: The model number of this Home Battery Energy Storage System is SWP-48100RM.
- Q: Where is this Home Battery Energy Storage System manufactured?
- A: This Home Battery Energy Storage System is manufactured in China.
- Q: What types of batteries are used in this Home Battery Energy Storage System?
- A: This Home Battery Energy Storage System uses Lithium Ion batteries.
- Q: Does this Home Battery Energy Storage System need professional installation?
- A: This Home Battery Energy Storage System does not need professional installation. It is easy to install and comes with detailed instructions.
